CAT 5e U/UTP
Unscreened four-pair data cable using 24 AWG solid bare-copper conductors. Intended for general Ethernet horizontal cabling where external electromagnetic interference is controlled.
NK Cable Systems
Networking Cables
NK networking cables provide structured copper-cabling solutions for reliable high-speed data transmission across commercial, industrial and infrastructure environments. The range includes unscreened and screened CAT 5e, CAT 6 and CAT 6A architectures with indoor, outdoor, PVC, LSZH and PE jacket options. CCT considers channel length, insertion loss, crosstalk, electromagnetic exposure, shield bonding, Power over Ethernet loading and installation environment when coordinating the cable system.
Applications
- Commercial structured-cabling systems
- Office and enterprise networks
- Data centres and equipment rooms
- Industrial Ethernet networks
- Building-management systems
- IP CCTV and security systems
- Access-control and intercom networks
- Wireless-access-point connections
- Voice-over-IP systems
- Power over Ethernet devices
- Outdoor and moisture-exposed data links
- Electrically noisy industrial environments
Product range
Illustration from range brochure
CAT 6 U/UTP
Unscreened four-pair, 24 AWG solid-copper cable with HDPE-insulated pairs. Designed with tighter pair geometry and crosstalk control than CAT 5e.
Illustration from range brochure
CAT 6 S/FTP
Four individually foil-screened 24 AWG twisted pairs with an overall tinned-copper braid. Provides low transfer impedance and enhanced immunity to electromagnetic and radio-frequency interference.
Illustration from range brochure
CAT 6A U/UTP with waterproof tape
Unscreened four-pair, 23 AWG solid-copper CAT 6A cable incorporating a water-blocking tape for moisture migration control in external or wet-route installations.
Illustration from range brochure
CAT 6A U/UTP
Unscreened four-pair, 23 AWG solid-copper cable with HDPE insulation. The larger conductor and controlled pair geometry support lower insertion loss and improved alien-crosstalk performance.
Illustration from range brochure
CAT 6A U/FTP
Four individually foil-screened 23 AWG twisted pairs without an overall shield. Pair-level screening reduces internal crosstalk and improves high-frequency noise immunity.
Illustration from range brochure
CAT 6A F/UTP
Four unscreened 23 AWG twisted pairs surrounded by a common overall foil screen. Provides system-level EMI protection while retaining simpler termination than individually screened pairs.
Illustration from range brochure
CAT 6A F/FTP
Four individually foil-screened 23 AWG pairs plus an overall foil shield. Provides high screening effectiveness and crosstalk isolation for electrically noisy environments.
From specification to delivery
CCT supports the cable package from the first electrical requirement through technical approval, procurement and delivery.
